Features
| Suitable for light load medium load operations in wide range of applications. |
| Equipped with 16 I/O and is easily expandable for more complex applications. |
| Equipped 6 I/O bus connection inside for easier cable management. |
| Provide 3 mounting methods : Floor, Upside-down,and Angle mount. |
Application
 |
 |
 |
Optional
| Type L | Payload (kg) | Reach (mm) | Pos.rep (mm) | Protection | Axis | Remark |
| LRA596-4-6A-L | 4KG | 596 | ±0.02 | IP54 / IP67 | 6 | Standard |
| LRA596-4-6H-L | 4KG | 596 | ±0.02 | IP54 / IP67 | 6 | Hollow |
| LRA707-7-6A-L | 7KG | 707 | ±0.02 | IP54 / IP67 | 6 | Standard |
| LRA707-7-6H-L | 7KG | 707 | ±0.02 | IP54 / IP67 | 6 | Hollow |
| LRA906-7-6A-L | 7KG | 906 | ±0.03 | IP54 / IP67 | 6 | Standard |
| LRA906-7-6H-L | 7KG | 906 | ±0.03 | IP54 / IP67 | 6 | Hollow |
| Type M | Payload (kg) | Reach (mm) | Pos.rep (mm) | Mounting | Protection | Axis | Remark |
| LRA705-5-6A-M | 5KG | 705 | ±0.05 | Floor, Upside-down, Angle | IP54 | 6 | Standard |
| LRA900-5-6A-M | 5KG | 900 | ±0.05 | Floor, Upside-down, Angle | IP54 | 6 | Standard |
| LRA1468-10-6A-M | 10KG | 1468 | ±0.08 | Floor, Upside-down, Angle | IP54 | 6 | Standard |
| LRA1598-10-6A-M | 10KG | 1598 | ±0.08 | Floor, Upside-down, Angle | IP54 | 6 | Standard |
| LRA1717-20-6A-M | 20KG | 1717 | ±0.08 | Floor, Upside-down, Angle | IP54 | 6 | Standard |
| LRA1758-5-6A-M | 5KG | 1758 | ±0.08 | Floor, Upside-down, Angle | IP54 | 6 | Standard |
| LRA2000-60-6A-M | 8KG | 2000 | ±0.08 | Floor, Upside-down, Angle | IP54 | 6 | Standard |
| LRA2100-60-6A-M | 60KG | 2100 | ±0.3 | Floor | IP54 | 6 | Standard |
Technical Specification
 |
Robot Work Envelope |
 |
Robot Base Dimension |
 |
Robot Flange Dimension |
