Features
Industrial Level UV Roll to Roll Printer
RR 3200G is High printing speed & High resolution Industrial UV Printer which will meet the speed and quality request of clients. It is equipped
with 2-6units Grey Scale micropiezo printheads, 4/6/8 colors high productivity print is available which is to satisfied the clients when clients are
with big batch production order.
 |  |  |  |
Highlight Features
Printer Details
Simple Operation Application
High Quality Printing Effect
 |
Igus Brand Carrier Chain Super Precision with Low Friction Noise |
 |
High Accuracy Inflatable Media Take-up Roller Media stepping stretching tension is adjustable to keep media going accurately. |
 |
THK High Precision Mute Linear Railr Greatly reduce noise during carriage moving and improve linear rail smooth-going, use life and lubricating efficiency. |
|
High Precision Heavy Roller High Precision Heavy Roller |
 |
Ricoh GEN5 Printhead Type: GEN 5, 7PL, printing speed is up to 45m2/h, resolution is up to 2400DPI. The image is exquisite and the effect is amazing. |
 |
Accurate Suction Control with Printing Table Suction from printing table is adjustable, it will avoid media wrinkle and keep printing resolution more table . |
 |
Ink Lack Alarm System Device Main ink tank equipped with automatic alarm system, and alarm light will flash when the ink is lack. |
 |
Data Statistics: After each picture is printed completely, the computer automatically statistics the amount of ink consumption, the printing time, the area and so on. |
 |
The printed image is more delicate and brighter, which improves the expressiveness of the picture, it is more real and with a great vision impact. |
 |
Intelligent Feather Printing Technology: The unique intelligent feather printing technology can improve the curable reflective stripes which occurred in the printing process, so that the printing quality can reach the ideal state. |
 |
3D Effect: The printer can print on the transparent film with 3D effect to make your advertising picture different and attractive. |
 |
Varnish Effect: After each picture is printed completely, the computer automatically statistics the amount of ink consumption, the printing time, the area and so on. |
Applications
 |
 |
 |
 |
 |
 |
Technical Specification
| Model | RR 3200G |
| Print Size | 3200mm |
| Printhead | Ricoh GEN 5 (7PL) |
| Ink Color | C,M, Y, K, LC, LM, W, Varnish ( optional) |
| Print Resolution | 720*600DPI; 720*900DPI; 720*1200DPI; 720*2400DPI |
| Print Speed | Production Mode 50m2/h, Quality Mode 30m2/h, High Quality Mode 23m2/h |
| Rip Software | RIP Center |
| Print File Format | TIFF, JPEG, PDF, EPS, PNG, etc. |
| Curing System | LED UV System |
| Available Printing Media | Wall Paper, Film, Photo Paper, Flex, Banner, PP Film, Vinyl, One-way Vision, Inkjet Fabric, etc. |
| Power | AC 220V +/- 10%, 50HZ/60HZ |
| Power Rating | 6.5KW |
| Media System | Roll to Roll, Automatic Media Feeding & Take-up System |
| Working Environment | Temperature: 15℃-28℃,Humidity: 40%-70% |
| Printer Dimension | 5100mm*1250mm*1600mm (Length*Width*Height) |
| Packing Dimension | 5200mm*1440mm*1850mm (Length*Width*Height) |
| Computer Configuration | Computer System: Win 7, 64 bit; Port USB 2.0/3.0, Hard Disc: More than 500GB; GPU Memory: 8GB; CPU: Intel i5 |
| *Specification are liable to change without prior notice. | |
