UNO Roll to Roll 1802/1602

UNO Roll to Roll 1802/1602

The UNO Roll-to-Roll series offers cost-effective, eco-solvent printing for banners, vinyl, and other flexible materials.

Model : UNO 1601 / UNO 1602 / UNO 1802
Print Heads : One Epson I3200 U1 / Two Epson I3200 U1
Technology : Drop-on-demand Piezo with Variable Dot

Immediate Contact No.

Building a Reliable
Technical Experience!

Ever since incorporation, we have been making our way through futuristic technology and ground-breaking innovations.
Product

Product Description

The UNO Roll-to-Roll series offers cost-effective, eco-solvent printing for banners, vinyl, and other flexible materials. Featuring Epson i3200 printheads, it ensures vibrant, detailed prints with efficient ink usage. Its pre-, mid-, and post-heating system guarantees consistent drying, while the robust feeding mechanism enables smooth media handling for uninterrupted production.

Product Overview

Original Epson U1 Print Heads

Epson I3200-U1 is a cost-effective 1.33inch-wide MEMs head series providing high productivity and high image quality with 600 dpi high-density resolution.This printhead is suitable for UV inks.

Anti-collision unit

Anti Collision unit – Detects and avoids objects that could contact print head (e.g., breakage, damaged edge, folded corner).

Precise & adjustable stepping system

Serried pinch rollers, one-piece grid roller and pressure adjuster assure accurate and wrinkle-free media stepping for different thicknesses of materials.

Variable Dot Technology

Variable dot technology for smoother gradations is a functionality of the print head that enables the creation of ink drops of different sizes onto the media, delivering smooth gradations and higher image quality.

Taking up System

The take up system has forward and reverse wind capability and offers adjustable roll widths, making it suitable for different sized media rolls and applications.

Product Features

EPSONI3200 U1 HIGH SPEED PRINT HEAD

INTELLIGENT NEGATIVE PRESSURE SYSTEM

HIGH-PRECISION SILENT LINEAR RAIL

IGUS(Germany) BRAND SUPER CARRIER CHAIN & CABLE SUPER PRECISION WITH LOW NOISE.

Technical Specification

Model UNO 1601 UNO 1602 UNO 1802
Print Head One Epson I3200 U1 Two Epson I3200 U1 Two Epson I3200 U1
Printing Speed
Mode Resolution UNO 1601 UNO 1602 UNO 1802
4 Pass Production 360 x 1200dpi 160 sq.ft./hr 320 sq.ft./hr 352 sq.ft./hr
6 Pass Production 360 x 1800dpi 110 sq.ft./hr 220 sq.ft./hr 242 sq.ft./hr
Technology Drop-on-demand Piezo with Variable Dot
Ink UV Ink
Color CMYK / CMYK+W
Ink Supply System Bulk Ink Supply System With Ink Cartridges
Ink Tank 500 ml
Printing Width Max. 1600mm Max. 1600mm Max. 1800mm
Media Type Banner, Coated PP, Vinyl, PVC Film, Backlit,PET Film..
Roll Diameter Max. 300mm
Roll Weight Max. 50kgs
Core Diameter 3 in (76.2mm) or 2 in (50.8mm)
Data Interface Ethernet (Speed 1GBPS)
Working Environment Temp.23℃~29℃, Humidity:50%~80%
Software PhotoPRINT
Power Single Phase 50Hz/AC,220V+10%
Dimensions (LxBxH) 3050 x 1451 x 960 mm 3050 x 1451 x 960 mm 3250 x 1451 x 960 mm
Weight 421kg 421kg 500kg

Specifications are liable to change without prior notice. All trademarks mentioned are property of their respective owners.
