➔More precise and durable heavy-duty body.
➔Revolutionary print head with RediJet Tech.
➔Negative Pressure Recirculation System.
➔2X Power Panasonic servo system.
➔Separate taking up with standby function.
➔Advanced color management software.
 |
A wide range of application solution
With continuous inc recirculation and robust repairable construction, Dimatix Starfire 1024 print head delivers unparalleled saturation and smooth gradient. |
 |
Staggered three rows of heads!
6 Starfire heads stagger in 3 rows for big volume output. CNC aluminum mounting with hard anodizing layer prevents its mechanism from deforming. |
 |
Gntech recirculation solution!
GZ Negative pressure recirculation system with compensation function perfectly plays the advantages of Starfire head, assuring steady ink delivery and minimizing downtime and maintenance. |
 |
Super strong heavy duty body!
Enhanced aluminum beam, beam holders and body frame assure extreme high speed printing&long running life and also prevent deforming during transportation. |
 |
Four heaters plus smart IR drying system!
Pre, mid, post, extended heaters plus IR drying system treats the media and prints evenly and efficiently during high speed printing. Synchronization IR dyring prevents the prints over-burnt and saves energy. |
 |
Separate taking up system!
Separate media taking up system with IR drier could dry the printing thoroughly during high speed printing. An additional roll saves media switching time to speed up production. |
| ITEM | SPECIFICATIONS | |
| Model | GZH 3206SG | |
| Print Head | 6 Starfire 1024 staggered in 3 rows | |
| Ink | C.M.Y.K solvent/eco-solvent | |
| Ink Supply System | Gntek Negative Pressure Recirculation System | |
| Printing width | Max. 3200mm | |
| Media Type | Banner, Frontlit, Backlit, Vinyl, Film… | |
| Media Delivery System | Automatic media feeding and taking up system with pneumatic shaft | |
| Drying System | Pre, mid, post and extended heater + smart IR drying system | |
| Printing Speed | 300x400dpi 375m 2/h, 300x600dpi 253m 2/h, 300x800dpi 191m2/h. | |
| Data Interface | External : USB2.0+; Internal: High-speed SCSI | |
| Working Environment | Temp. 23° C ~29° C, Humidity: 50%~80% | |
| Software | Onyx+GZ control console | |
| Power | 50Hz/AC 220v + 10% 3A(Printer)+10A(IR drying system) | |
| Installed / Package size | L*W*H(mm): 5500*1100*1670 / 5600*1550*1880 | |
| G.W / N.W | 1512kgs / 1262kgs | |
| Specifications are liable to change without prior notice. All trademarks mentioned are property of their respective owners | ||
