The RT 2513FR UV hybrid printer is built for versatile printing on both roll and rigid substrates.
Model : RT 2513 FR
Print Heads : 3 Epson T 3200 U3 print head ( Standard ) Up to 6 print head ( Optional ).
Technology : Piezoelectric on-demand Inkjet technology with grayscale capability.
The RT 2513FR UV hybrid printer is built for versatile printing on both roll and rigid substrates. Equipped with Ricoh Gen6 heads, it delivers vibrant CMYK, white, and varnish output. Its efficient vacuum table and precise media handling make it ideal for signage, retail displays, and packaging. Built for speed and reliability, it ensures seamless production.
High speed than any regular UV Printers, thanks to its electronics & Panasonic AC Servo Motor.
Z-Axis Movement up to 100 mm, One can print on 100 mm thickness media.
RasterJet UV printers are equipped with latest silent LM guide.
All AC Servo motors and drives are from Panasonic (Japan), for long life, trouble and maintenance free operation.
Smart printing technology enable to higher productivity.
White ink recirculation system is preventing to sedimentations of ink pigment.
Mechanical structure achieves high-precision printing To reduce printer unit vibration, the print table moves during printing instead of the Y-bar, ln addition, to achieve higher position accuracy, two ball screws are installed on both sides of the table to assist with its movement. RasterJet UV flatbed printers offers high performance printing that satisfies the position accuracy necessary for additional printing on preprinted surfaces. Furthermore, fine lines, edges, and small texts are clearly represented. RasterJet UV flatbed printers are the best digital on demand printing solution for the screen printing industry.
RasterJet Optimizations Level System Level 1: Remove the band even in bi-direction mode Level 2: Using the optimizations one cannot see the effect on printing even if some nozzles are clogged. Level 3: Intelligent Feather Printing Technology, The unique intelligent feather printing technology can improve the curable reflective stripes which occurred in the printing process, so that the printing quality can reach the ideal state.
Variable dot printing Optimum droplet sizes are automatically selected from 6PL to 30PL for each print mode. Moreover, Rasterjet UV flatbed printers can separately control droplet size for process color (CMYK) and spot color. This capability is useful for simultaneous double-layer printing. Small droplet are used for color printing to present a delicate finish, and large droplet are used for white-base-layer printing to obtain high opacity.
| Model | RT 2513 | RT 2513 FR | RT 3220 |
| Printing Technology | Piezoelectric on-demand inkjet technology with grayscale capability | ||
| No. of Printheads | 3 EPSON T3200 U3 Print Heads (Standard) Up to 6 Print Heads (optional) | ||
| Printable Media Size Flatbed | 2500mm x 1300mm | 2500mm x 1300mm | 3200mm x 2000mm |
| Printable Media Size Roll to Roll | - | 2500mm width | - |
| Printing Resolution | 1200 dpi | ||
| Acceptable Media Thickness | Up to 100mm | ||
| Ink type | UV LED curable ink | ||
| Ink Capacity | 1.5 Liter Bottle | ||
| Colours | Cyan, Magenta, Yellow, Black, White | ||
| Configuration | (1) CMYK + White, (2) White + CMYK, (3) CMYK + White + CMY | ||
| Ink Curing Unit | Dual LED Lamps | ||
| Software | Onyx RIP Center | ||
| Interface | Highspeed USB 3.0 | ||
| Power Supply | 100-110V AC / 220-240V AC, 50/60Hz | ||
| Required Power Capacity | For Printer Operation (15A) max, + For Vacuum Platform (15A) max | ||
| Power Consumption | Maximum 6.8kVA | ||
| Dimensions (mm) | L 2228 x W 4310 x H 1432 | L 2800 x W 4350 x H 1600 | L 2776 x W 5000 x H 1366 |
| Weight | 1150kg approx | 1400kg approx | 1600kg approx |
| Working Environment | (Power on) Temperature: 21°C to 30°C (69°F to 86°F) / Humidity: 35 to 80%(Power off) Temperature: 5°C to 40°C (41°F to 104°F) / Humidity: 20 to 80% | ||
