The Die Board Laser Cutting Machine is designed for high-precision cutting of plywood die boards.
Model : HEXA LD 1224
Power Consumption : 5 KW
Memory : 128 MB
Ultra Compact next generation Co2 laser tube cut a wide variety of material with incredible accuracy. No consumable parts and long operating lifetime performance, Synrad is the only CO2 laser manufacturer that can boast of proven operating lifetimes in excess of 45,000 hours (at which time, a simple and inexpensive gas rell returns the laser to full operation). The New Vi Series includes a new Temperature Broadcast feature for real-time condition monitoring and the design efficiently manages thermal resistance and power to deliver a stable accurate beam. The Vi Series are some of the most compact and lightest 30 W and 40 W COâ‚‚ lasers.
Maximum power and performance from an air-cooled CO₂ laser is the drive behind their restar Ti series technology, Synrad’s restar Ti series lasers are built on technology using a patented hybrid, unstable resonator design.
The auto focus tools helps to adjust and x focal length by automatic table up and down. It saves the time of setting the right distance (focal length) between head and top surface of the materials when you work with more materials having different thickness. Right focal length is the most important to get good quality engraving.
The linear guideway body consists of an anodized aluminum housing with a chrome steel gcr15 shaft which is of low friction, noise and vibration. The pulleys/pinion is equipped with maintenance free U shape bearings. It redene the classic belt drive, putting belts to work in an entirely new way that reduces the positioning errors and speed limitations of conventional belt drives. Mehta’s linear modules provides high load capacities, high speed, accuracy and repeatability. The linear bearing system is corrosion resistant, even after scratching.
ERICA’s lastest laser engraving & cutting control system has better stable hardware with antistatic, resistance to high pressure. Based on 5-inch colorful screen, human-machine operation system, with better operation interface and stronger functions, excellent motion control functions, high-capacity le memory, with strong compatible 2-way independent adjustable laser power control interface, strong compatible U disk drive program, multiple ways general/dedicated IO control.
Virtual Printer Mode, File Send Direct From CorelDRAW
It has Anti-Collision function and it supports cut 2 pt, 3 pt, 4 pt at 1 die board single time.
ARROW shape working platform reduces the blackening of the cutting surface.
Fixed laser path, ensures stable optical path.
Laser head can automatically adapt to jagged material, ensuring uniform cutting seam.
Large gantry milling and high-temperature heat treatment working table, can be used for long years without deformation.
Off-line control system, it’s easy to set up cutting parameters on LED screen.
Sealed laser path and clean environment offer a long-time lifespan for the lens.
Highly effective and optimized exhaust system to reduce smoke during working and maintain a healthy environment.
| MODEL | HEXA LD 1224 |
| Power | 600 watt |
| Working Area | 1200 X 2400 mm |
| Laser Source | Co2 Direct Current Simulated Glass Laser Tube |
| Cutting Depth | 15 to 18 mm Plywood |
| Cutting Speed | 30-35 m/H 18 mm plywood |
| Mould Knife Thickness | 0.45 mm, 0.71 mm, 1.07 mm |
| Cutting Precision | +/- 0.05 |
| Numeric Control Panel | LCD Screen Light Touched Key Press. |
| Transmission Systems | AC Servo Motor and Driver (Japan) |
| Graphic Format Support | HPGL, PLT, AI, DXF |
| Memory | 128 MB |
| Interfacing | USB, U-Disk, Ether Cat |
| Power Supply | AC 3 phase |
| Power Consumption | 5 KW |
| Operating Temperature | 0 to 45ºC |
| All Over Dimension | L 4008 mm x B 4092 mm x H 1625 mm |
