Presto PR-A1-2616 multipass inkjet printer with industrial-grade thermal foaming printhead.
Model : PRESTO PR-A1-2616
Print Heads : Micro-Piero Hi-End Printhead
Platform: Vacuum Adsorption
Presto PR-A1-2616 multipass inkjet printer with industrial-grade thermal foaming printhead. Designed for the printing and packaging industry, it supports A, B, C, and E corrugated cardboard as well as honeycomb boards. Plate-free digital printing eliminates plate making and simplifies job setup. Orders can be changed in about a minute, helping reduce inventory needs. Features CMYK computer color grading, low power consumption, and a cleaner printing process suitable for modern packaging production.
MULTI-TASK CONTINUOUS PRINTING, NO INDIRECT AUTOMATIC SWITCHING OF PRINTING PICTURES.
KRAFT PAPER BAGS, ENVELOPE, CARDBOARD ETC. SUITABLE FOR BATCH PRINTING.
SUPPORT ROLL TO ROLL FLEXIBLE MATERIAL PRINTING AND THERE IS NO PRINT LENGTH LIMIT.
BOTH PIGMENT INKS ARE DYE INKS CAN BE USED.
HIGH DEFINITION TOUCH SCREEN & USER FRIENDLY OPERATION.
THE COMBINATION DESIGN OF PRESSING SHEET ENSURE THAT THE MATERIAL PASSES UNDER THE PRINT HEAD SOOTHLY AND STABLE TO PREVENT DAMAGE TO THE PRINT HEAD.
| Model | PRESTO PR-A1-2616 | |
| Print Heads | Micro-Piezo Hi-End Printhead | |
| No. of Print Heads* | 16 Nos. | |
| Maximum Printing Width | 2600 mm | |
| Printing Speed | Upto 700 Sq.Mtr per hr. | |
| Ink Color | CMYK | |
| Ink Type | UV Water Based Ink, Waterproof Ink, UV Ink | |
| Max Printing Resolution | ≥ 360 x 600 dpi | |
| Min Text Size | 1.5 mm Digital, English 1.5 mm | |
| Dying Speed | Dying After Printing for carton (The Others according to different materials) | |
| Ink- Provide | Two Ink Supply, Fully Enclosed Ink Suppy Channel Efficiency | |
| Feeding Material | Automatic | |
| Supported Format | PDF, JPG, BMP, TIF | |
| Platform | Vacuum Adsorption | |
| Material Thickness | 2-30 mm | |
| RIP | Supported Direct Printing Without Converting Pictures | |
| Rated Power | 10 KW | |
| Electricity | 380V±10%, 50/60HZ, 3Ph | |
| Electric | Schneider | |
| Electricity Machinery | Delta | |
| Graphic Control Panel | Delta | |
| PLC | Delta | |
| Machine Size | 4260 mm x 2000 mm X 1800 mm | |
| Working Environment | 15°C-32°C, Humidity 70% | |
| Weight | 2800 Kg. | |
Specifications are liable to change without prior notice. All trademarks mentioned are property of their respective owners
