High Speed Laser cutting and Engraving Machine (3D scan head system)
ERINA 100G
Features
| With high speed digital galvo, combined with dynamic shaft drive, can realize the large area work size marking and 3d surface marking. |
| Optimisation of optical design and optical lens combination, reduces optical loss and component costs, as well as improves laser use efficiency. |
Application
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
Technical Specification
| Model | ERINA 100G | |
| Laser Power | 80W / 100W | |
| Wavelength | Co2 Laser 10.6 um | |
| Operating System | Win 7 / 10 ( 32 bit / 64 bit) | |
| Working Environment | 15°C – 30°C, Humidity 30% – 80% | |
| Working Area | 400 x 400 mm to 600 x 600 mm | |
| Graphical Format | PLT, DXF, BMP, JPG, TIF | |
| Power Supply | 220V / 50Hz / 60Hz | |
| Cooling Method | Water Cooled | |
| Scan Head | 3D Dynamic Galvo System | |
| Max. Speed | Max. 5000 mm/s | |
| Min. Latter Size | 1 mm | |
| Repetition Accuracy | 0.01mm | |
| Consumption | 3 Kw | |
| Dimensions (LxWxH) | 2600 mm x 625 mm x 1570 mm | |
| *Specification are liable to change without prior notice. | ||
