Features
Dieless Cutting
Automatic Loading & Unloading System (Optional)
High Speed, High Precision, Creasing up-to 5mm Board
Best For Shortrun / Longrun Job
Best For Sample Box Making
Precision Cutting and Creasing With Camera System
Technical Specification
| Model | SWIFT 1209 |
| Working area | 1200 mm X 900 mm |
| Feeding Mode | Auto Feeding (optional) |
| Max. Cutting Speed | 2000 mm/s | Cutting Precision | 0.2 mm/mtr |
| Max. Cutting Thickness | Â 5 mm |
| Tools | Kiss Tool & Creasing Tool (Optional Tools : EOT, POT, Rotary Driven, Drag Tool) |
| Vision System | Yes |
| Transmission | Z Axis Transmit by Ball Screw & X, Y Helical Rack And Pinion |
| Controller | DSP Controller |
| Motor | Servo Motor with Gear Box |
| Data Formats | AI, PLT, DXF etc |
| Interface | USB or Network Interface |
| Media Absorption | Vacuum Absorption |
| Suction Fan Power | 7.5KW |
| Host Power Supply | 220V/ 50HZ |
| Fan Power Supply | 380V/ 50HZ |
| Operating Environment | Temperature 0° – 40°C, Humidity: 20% – 80% | *Specification are liable to change without prior notice. |
Applications
 |
 |
|||||
 |
 |
 |
||||
