The EVICO 1016 UV flatbed printer offers enhanced performance for larger media, combining high-resolution Ricoh printheads with CMYK, white, and varnish capabilities.
Model : RJ 7500 / RJ 1016
Print Heads : 6 x Rioch GH2220 Industrial Printhead
Technology : Variable Dot Printing ( Gray Scale Printing)
The EVICO 1016 UV flatbed printer offers enhanced performance for larger media, combining high-resolution Ricoh printheads with CMYK, white, and varnish capabilities. Its strong vacuum table, advanced automation, and durable build ensure precise printing on substrates like metal, glass, and wood. Perfect for signage, décor, packaging, and customized product industries.
High speed than any regular UV Printers, thanks to its electronics & Panasonic AC Servo Motor.
Z-Axis Movement up to 100 mm, One can print on 100 mm thickness media.
RasterJet UV printers are equipped with latest silent LM guide.
All AC Servo motors and drives are from Panasonic (Japan), for long life, trouble and maintenance free operation.
Smart printing technology enable to higher productivity.
White ink recirculation system is preventing to sedimentations of ink pigment.
| TECHNICAL SPECIFICATION | EVICO 1016 |
|---|---|
| Printhead | Epson I3200 U1 |
| No. of Printheads | Up to 3 Printheads (Optional 4 Printheads) |
| Color | CMYK, White, Varnish |
| Structure | Industrial Structure Frame with Heavy Duty Y-Bar |
| X & Y Motor | AC Servo Motors |
| Maximum Print Size | 1000mm (W) × 1600mm (H) (75mm Thickness) |
| Printing Resolution | 2400 dpi |
| Printing Direction | Uni and Bi-Direction |
| Printing Technology | Variable Dot Printing (Grey Scale Printing) |
| Ink Type | UV LED Curable Inks |
| Ink Capacity | 1.5 Liter Bottle |
| Ink Supply System | Negative Pressure System (NPS) with Automatic Ink Supply |
| UV Technology | UV LED Lamp |
| RIP | PhotoPRINT / Onyx |
| Media Type | Acrylic, Sun board, PVC board, MDF, Leather, Metal, etc. |
| Data Interface | Ethernet (1 Gbps) |
| Power Consumption | Maximum 3 KVA |
| Power Requirements | Single Phase, 50Hz AC, 220V ±10% |
| Dimensions (mm) | L 2330 × W 2122 × H 1259 |
| Net Weight | 510 kgs |
Specifications are subject to change without prior notice.
