The GLORIA MR large-format fiber laser cutting machine is specially designed for cutting extra-large metal sheets and plates with high precision and stable performance. It features a gantry-type structure with ground-rail transmission, ensuring excellent rigidity and accuracy even over long travel distances.
Model : GLORIA-MR
Cutting Head : Bochu
The MR Series Large Format Fiber Laser Cutting Machine is designed for high-precision cutting of extra-large metal sheets with stable and efficient performance. Built with a robust gantry structure and advanced ground-rail transmission system, it ensures consistent accuracy even over long working distances.
Powered by a high-performance fiber laser source (12 kW to 80 kW), the machine delivers fast cutting speeds, clean edges, and reliable output for heavy-duty industrial applications. Its extra-large working area allows processing of oversized sheets, making it ideal for large-scale production.
Equipped with an intelligent remnant reuse system, it helps optimize material utilization and reduce wastage. The machine also features advanced safety protection, a separate workbench and transmission design for better stability, and advanced bevel cutting technology for complex cutting requirements.
High quality rack & pinio , LM guid , gear box
Machine Frame and worktable adoptsintegrated welding made as standard large machine after stress relief annealing, machining on plano miller and then the vibration aging treatment. These sequence of processing of frames makes it high strength, high precision and keep the normal use of 20 years without deformation.
Suit for QBH/OD connector.
Enjoy high speed of auto focusing via collimation with servo motor.
Strict dust-proof design with three protection windows.
Separate drawer of focus protection window is convenient for maintenance and replacement.
All optics temperature monitor; air leakage monitor, protection window in place monitor.
Real-time feedbacks of processing states will be uploaded to mobile APP as well as PC, and alarm can be released immediately.
Processing states can be shared on Wechat, QQ, OS-CUTTING.
| Model | MR |
| Laser Power | 12000 to 80000 Watt |
| Maximum Linkage Speed | 130 m/min. |
| Positioning Accuracy | 0.1± |
| Repeatability | 0.1± |
| Max. Acceleration | 0.5G |
| Cooling System | Water Cooling |
| Drive & Control | AC Servo Motor |
| Working Voltage | AC 420V |
Specifications are liable to change without prior notice.
