SINO 3202SK

  • Platform Suction Adjustable System.
  • Manually Adjustable Platform Suction
  • Multi-Heating & Drying System.
  • High Strength Steel Body Frame and High-Precision Liner Rail.
  • Electronic Nozzles Flash Control.
  • Automatic Negative Pressure Adjustment With Individual Cleaning System.
Panasonic A6 Servo System Igus Brand Carrier Chain (Germany)
High Torque yet Low Vibration; Stable, and Accurate Printing. Super Precision with Low Friction Noise
Robust, Durable and Precise Manufacturing Anti Collision System
CNC Aluminium Beam support with Dual Linear Guides for High Speed Printing. Anti Collision System to Protect Print Head during High Speed Printing.
IR Heater with Drying Fans SAI Flexi Print 19 MCC Edition (RIP Software)
Powerful IR Heater with Enabling High Speed Printing Capability. Empower tour workflow with efficient tools and features designed for all production environments.
Model SINO 3202SK
Print Heads 2 Seiko 1024HG Print Head
Speed
Mode Resolution Speed
2 Pass 480 x 360dpi 1180 sq.ft./hr
3 Pass 480 x 540 dpi 697 sq.ft./hr
4 Pass 480 x 720 dpi 500 sq.ft./hr
Technology Piezo Drop on Demand Inkjet Technology
Ink C.M.Y.K Solvent / Eco Solvent
Ink Supply System Auto Consistent Ink Supply With Negative Air Pressure System
Feeding System Automatic Media Feeding System with Infrared Sensor / Taking Up (optional)
Drying System Pre, Mid, Post Heater + IR Drying System
Printing Width Max. 3200mm
Media Type Paper, PVC, Banner, Frontlit, Backlit, Vinyl, Film…
Rip Software Flexi Print MCC Edition
Image Format .PDF, .JPEG., .TIIF
Data Interface External: USB 3.0+; Internal: Fiber Optical Cable
Power Single Phase 50Hz/AC 220V±10%, 10A (Printer) + 16A (IR Drying System)
Working Environment Temp 23°C~29°C, Humidity: 50%~80%
Installed/Package Size LxWxH(mm): 4940 x 1047 x 1399 / 5040 x 1147 x 1499
N.W./G.W. 900kgs / 1000kgs
Specifications are liable to change without prior notice. All trademarks mentioned are property of their respective owners
