Features
| Pass through design for long length of work piece in Y-axis direction. |
| Machine is Provided with Foot-mounting legs so that there is no vibration in machine can be adjusted on zero level. |
| Laser cut software with windows based software enhance cutting speed & angle / curve performance. |
| The specially design create vacuum which holds the material strongly. |
| Special mirrors are used for long life even though bad fumes are generated from PU or some fabrics. |
| Strong and sliding honeycomb table. |
| High Quality of chiller unit for better performance and long life of laser tube. |
Application
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
Technical Specification
| Model | EVA 1610 R | EVA 1610 R2H | EVA 1610 RBC | EVA 1610 RBSC |
| X,Y Cutting Area | 1600 mm x 1000 mm | 1600 mm x 1000 mm | 1600 mm x 1000 mm | 1600 mm x 1000 mm |
| Laser Power | 80 W / 100 W / 130W | 80 W / 100 W / 130W | 80 W / 100 W / 130W | 80 W / 100 W / 130W |
| No. of Heads & Laser Tube | 1 | 2 | 1 | 1 |
| Traveling Speed | 800 mm/sec | |||
| Reposition Accuracy | 0.02 mm | |||
| Auto Feeding System | Optional | |||
| X Y Movement System | Belt Transmission | |||
| Red Beam | Yes | |||
| Power Adjustment | 1 to 100% | |||
| Working Table | Stainless Steel Conveyer Platform | |||
| Driving System | Stepper Motor / Servo Motor | |||
| Operating System | Win 7/8/10, 32 bit/64 bit | |||
| Interface | U-Disk, USB interface, Ethernet | |||
| Supported Format | PLT, DWG, DXF, BMP, JPG, AI, HPGL, DST | |||
| Working Voltage | AC220V ± 10%, 50Hz / 60Hz | |||
| Running Environment | 45℃, Humidity 5% – 80% | |||
| Camera Systems | No | No | 18 Megapixel HD DSLR Camera | 2 Megapixel Monochrome Camera & 18 Megapixel HD DSLR Camera |
| Memory Buffer | 128 MB | |||
| Overall Dimension (L x W x H) | 3440 x 2172 x 1030 mm | 3440 x 2172 x 1030 mm | 3440 x 2172 x 1030 mm | 3440 x 2172 x 1030 mm |
| Weight | 860 Kg | 860 Kg | 860 Kg | 860 Kg |
| Power Consumption | 3.5 KW | |||
| Specifications are liable to change without prior notice. All trademarks mentioned are property of their respective owners. | ||||
