VEGA 48

AC Servo Motor Technology For High Speed And High Precision Movement Control.
Red Beam Dot Pointer To Help You See The Expected Laser Beam Position For Cutting And Engraving.
Processing File Path Is Displayed Simultaneously When The Machine Runs.
USB Flash Drive Supports Read File Directly From USB Flash Drive Without The Use Of Computer.
>Power Brake Function: Re Continue Work After Power Off.
High Quality Of Chiller Unit For Better Performance And Long Life Laser Tube.
Machine Is Provided With Foot-mounting Lags So That There Is No Vibration In Machine And Machine Can Be Adjusted On Zero Level.
Machine Is Provided With Heavy Duty Compressor Which Has Air-assist Combining Adjustable Focus. Systems In Coaxial Jet Air To Prevent Cutting Edge From Burning Down.
Model VEGA 43 VEGA 48
Watt 100 / 130 / 150 Watt 220 / 300 Watt
Working Area 1220 x 915 mm ( 48 inch *36 inch) 1220 x 2440 mm ( 48 inch *96 inch)
Engraving Area 1150 x 915 mm ( 45 inch *36 inch)
Co2 Laser Source Sealed Glass Laser Tube Double Tubes Beam Combination Laser Tube
Positioning Accuracy 0.02 mm 0.02 mm (upto 300 mm/sec)
Drive A.C Servo Control (Japan)
Maximum Speed 40 IPS 10 m / min
Speed Control Adjustable from 0.1- 100% (up to 20 colour linked speed setting per job)
Power Control Adjustable from1.0 – 100% (up to 20 colour linked speed setting per job)
Z Axis Movement Manual up to 40 mm Motorized
Cooling Water Cooled
Resolution (DPI) Up to 4500 DPI
Supported Formats plt, dxf, bmp, jpg, ai, gip, tif
Focus Lens Standard 2” and 5” Inch
Maximum Cutting Depth 20 mm Acrylic 40 mm Acrylic
Memory Buffer 256 MB
Red Dot Pointer Yes
Computer Interface USB -A For USB Storage, USB – B For Connection, Ethernet
Display Panel 5 Inch Colour Full LCD Screen Showing Current File Name, Total Working, Laser Power, Engraving Speed
Cutting Table Knife Shaped Cutting Aluminium Strip
Computer Systems Win 8/10 , 32/64 bit
Power Consumption 2.5 kw 4.0 kw
Operating Voltage 220-230AC ,50/60 HZ, 20A
Fume Extraction Systems External Exhaust System With Minimum Flow Rate 1200m3/h.
Weight 385 kg. 750 kg.
Outer Dimensions (mm) 1471 L x 1840 W x 1090 H 3600 L x 1900 W x 1000 H
Specifications are liable to change without prior notice.
